HD-1615 ultrasonic welding machine is a customized machine which is designed for highly automated production of plastic zipper. This machine uses ultrasonic welding (four edges), forming and punching to replace the traditional craft. Its products have the advantages of firmly welding, precisely welded edge, symmetrically welded zipper, flat and symmetrically punching. It uses ultrasound system made in Taiwan to ensure strong output and stable performance. This ultrasonic welding machine support automatic material feeding and automatic material dispensing. Its humanization operation interface is easy and convenient to use.

Specifications

• Dimension: 3850mm*975mm*1550mm
• Capacity: 20-40 pcs/min
• Voltage: 220V/380V
• Air Pressure: 3-6KG/CM²
• Frequency: 20 KHZ
• Power: 3700W
• Weight: 800KG

Features

• This ultrasonic welding machine uses ultrasound system made in Taiwan which is highly stable and reliable.
• NTK Transducer ensures strong output.
• Integrated system and humanization operation interface makes this machine easy and convenient to use.
• This ultrasonic welding machine is highly automated. It supports automatic material feeding, automatic material dispensing, automatic forming and punching, automatic product output. It has integrated multiple automated stations.
• Its products have the advantages of firmly welding, precisely welded edge, symmetrically welded zipper, flat and symmetrically punching.
• This machine has high production efficiency. Its capacity can be adjusted according to your requirement.
